All of our Insulated Roofing & Cladding Panels have been fire tested in accordance to BS EN 13501-1 and achieves Class Bs2d0.
Our Insulated Composite Sandwich Panels are available in stock lengths in one metre increments. Our lengths consist of: 3, 4, 5, 6 and 7m. Our PIR panels have an additional 75mm (0.75m) cutback.
Did you know that one of our 91,000 sqf warehouses is filled with Insulated Panels? Briarwood always make sure that our stock levels are manufactured to be above stock-max to ensure that we can fulfill all sized insulated panel orders.
High-performance insulated roof panel designed for pitched roofs from 4°. A rigid PIR core bonded between steel sheets delivers excellent thermal efficiency, strong spanning capability and rapid installation — ideal for agricultural, commercial and industrial roofing.
| Panel thickness | U-value (W/m²K) | Weight (kg/m²) |
| 80mm | 0.25 | 9.0 |
U-values calculated in accordance with EN 14509.
| Stocked lengths | 3000mm, 4000mm, 5000mm, 6000mm, 7000mm |
| Cover width | 1000mm |
| Profile height | 30mm |
| Rib spacing | 333mm centres |
| Cut-back | 75mm |
Characteristic loads (CC1, L/200). Loads in kN/m². Spans in metres.
| Span condition | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 |
|---|---|---|---|---|---|---|---|
| 1 Span | 5.95 | 4.80 | 4.06 | 3.55 | 3.02 | 2.40 | 2.14 |
| 2 Span | 4.66 | 3.93 | 3.42 | 3.05 | 2.66 | 2.15 | 1.93 |
| ≥3 Span | 5.15 | 4.32 | 3.76 | 3.35 | 2.91 | 2.36 | 2.12 |
| Span condition | 0.80 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 |
|---|---|---|---|---|---|---|
| 1 Span | 6.06 | 5.38 | 4.88 | 4.34 | 3.75 | 3.35 |
| 2 Span | 4.72 | 3.94 | 3.42 | 2.91 | 2.38 | 2.05 |
| ≥3 Span | 5.76 | 4.78 | 4.12 | 3.44 | 2.75 | 2.33 |
Briarwood are proud manufacturers of Composite Insulated Sandwich Panels for Roofing & Cladding applications.
We pride ourselves on the vast amount of manufacturing insulated panel stock we hold at our Highbridge Headquarters - allowing us to deliver at unbeatable rates and timeframes.
Made by Briarwood at our plant in Italy, alongside our Big 6 fibre cement.
Reach out to us to learn more about setting up an account with Briarwood! Our team of specialists can help you build orders, arrange delivery and provide you with an unbeatable service.
Apply for an account
High-performance insulated roof panel designed for pitched roofs from 4°. A rigid PIR core bonded between steel sheets delivers excellent thermal efficiency, strong spanning capability and rapid installation — ideal for agricultural, commercial and industrial roofing.
| Panel thickness | U-value (W/m²K) | Weight (kg/m²) |
| 80mm | 0.25 | 9.0 |
U-values calculated in accordance with EN 14509.
| Stocked lengths | 3000mm, 4000mm, 5000mm, 6000mm, 7000mm |
| Cover width | 1000mm |
| Profile height | 30mm |
| Rib spacing | 333mm centres |
| Cut-back | 75mm |
Characteristic loads (CC1, L/200). Loads in kN/m². Spans in metres.
| Span condition | 0.60 | 0.80 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 |
|---|---|---|---|---|---|---|---|
| 1 Span | 5.95 | 4.80 | 4.06 | 3.55 | 3.02 | 2.40 | 2.14 |
| 2 Span | 4.66 | 3.93 | 3.42 | 3.05 | 2.66 | 2.15 | 1.93 |
| ≥3 Span | 5.15 | 4.32 | 3.76 | 3.35 | 2.91 | 2.36 | 2.12 |
| Span condition | 0.80 | 1.00 | 1.20 | 1.50 | 2.00 | 2.50 |
|---|---|---|---|---|---|---|
| 1 Span | 6.06 | 5.38 | 4.88 | 4.34 | 3.75 | 3.35 |
| 2 Span | 4.72 | 3.94 | 3.42 | 2.91 | 2.38 | 2.05 |
| ≥3 Span | 5.76 | 4.78 | 4.12 | 3.44 | 2.75 | 2.33 |
